High Speed Melamine Ware Press Machine Precision Control 400T Pressure Double Color

Brand Name : ZHENGTAI

Model Number : 250T

Certification : SGS,CE

Place of Origin : CHINA

MOQ : 1

Price : 22800

Payment Terms : L/C,T/T

Supply Ability : 20

Delivery Time : 5-7 WORK DAYS

Total Pressure : 400 tons

Pressing Method : Hydraulic Press

Machine Type : Double Color Press

Heating System : Electric Heating Plates

Control System : PLC Control with Touch Screen

Machine Dimensions : 2250 × 1360 × 2250 mm

Table Size : 700 × 800 mm

Contact Now

High-Speed Melamine Ware Forming Press Machine With Precision Control 400T Pressure Double Color
Our Melamine Tableware Hydraulic Press Machine is engineered for the precision manufacturing of high-quality melamine plates, bowls, trays, and various crockery items. Designed for durability and efficiency, this machine utilizes advanced hydraulic pressure systems to ensure uniform density and a flawless glossy finish on every piece of tableware. Whether you are producing single-color or multi-color (decal) melamine ware, our equipment offers the stability and control required for industrial-scale production.
Key Advantages
  • Cost-Effective: High cost-performance ratio with competitive unit pricing
  • Versatile Applications: Primarily serves A5 melamine product manufacturing and resin-bonded craft production, including hotel resin crafts, melamine tableware, chopsticks, toilet seat covers, appliance enclosures, molded storage bags, lampshade tops, and daily chemical products
  • Enhanced Productivity: Superior attention to production details and operator comfort increases production efficiency and product yield rates compared to other factory molding machines
  • Optimized Operation: Features smoother, faster movements with modular design for easier disassembly and maintenance. The insulated frame extends insulation panel lifespan, while asbestos-based insulation provides superior thermal performance.
High Speed Melamine Ware Press Machine Precision Control 400T Pressure Double Color
ZT400T Single Color Hydraulic Press Machine Specifications
Technical Parameter Specification
Cylinder Diameter 450 mm
Total Pressure 400 tons
Table Size 700 × 800 mm
Trip 560 mm
Guide Post Diameter 110 mm
Machine Weight 5500 kg
Machine Size 2250 × 1360 × 2250 mm
Oil Reservoir Capacity 486 L
Maximum Pressure 210 KG/CM²
Average Powder Consumption 11 KW/H
High Speed Melamine Ware Press Machine Precision Control 400T Pressure Double Color
Standard Machine Configuration
Component Included
Heat Shield Standard
Heating Plate Standard
Heating System Standard
Electric Machinery Standard
Oil Pump Standard
Solenoid Valve Standard
Full Oil Valve Standard
PLC Control System Standard
POD Interface Standard
Why Choose Our Melamine Compression Machine?
High Yield Rate
Minimize rejects with precise temperature control (±1°C) and pressure stability for consistent product quality
Material Versatility
Suitable for various raw materials, including Melamine Formaldehyde (MF) and Urea-Formaldehyde (UF) molding powders
Fast Cycle Times
Optimized hydraulic movements reduce idle time, significantly boosting your daily production output
Global Compliance
Manufactured according to CE and ISO standards to meet international safety and quality requirements
High Speed Melamine Ware Press Machine Precision Control 400T Pressure Double Color
